AMF Thermatex Acoustic System

Two way exposed grid system
Dimensions
600 x 600 mm, 1200 x 600mm (other sizes available on request)

Thickness / weight
19 mm (c. 5.0 kg/m²)

Colour
White similar to RAL 9010

Sound absorption
NRC = 0.70 as per ASTM C 423

Sound attenuation
CAC = 40 dB as per ASTM E413-10

Sound insulation
Rw = 22 dB as per EN ISO 10848

Fire rating
Group 1-S (as per ISO 5660 Parts 1 and 2)

Light reflectance
up to 88%

Thermal conductivity
λ = 0.052 – 0.057 W/mK as per DIN 52612

Humidity
up to 95 % RH

Clean room
Class 3 as per ISO 14644-1
